Thermalrock S (Slab)

Plasterboard Ceiling Perforated Ceiling Double Skin Metal Wall Masonary Wall Lining Single Skin Metal Wall Unitized Curtain Wall Products

Thermalrock S (Slab) is an insulation slab designed for general insulation purposes. It is manufactured in a wide variety of thicknesses and densities to suit most requirements, suitable for general application in residential, commercial and industrial buildings.
Enquire Now View Datasheet
Overview Specifications & Sizes Tools, Guides & Downloads

Thermalrock S offers a wide range of multi-purpose usage in metal deck roofs, attics, ceilings, general partition application where no load-bearing insulation slabs are required. It may be used for metal stud partitions for easy installation where no sagging or slumping of the insulation product will occur.

ADVANTAGES

  • Simple and fast installation

  • No sagging/slumping, rigidity lasts for a lifetime of a building

  • Can be tailor made to various dimensions

  • Water repellent

  • Thermal insulant

  • Non-combustible and fire safe

Specification & sizes

Product ID Product Name Thickness (mm) Width (mm) Length (mm)
158891 Thermalrock S40 40 600 1000
201381 Thermalrock S40 50 600 1000
158898 Thermalrock S40 75 600 1000
158899 Thermalrock S40 100 600 1000
180501 Thermalrock S50 30 600 1000
158900 Thermalrock S50 50 600 1000
177762 Thermalrock S50 75 600 1000
158905 Thermalrock S50 100 600 1000
158906 Thermalrock S60 25 600 1000
158910 Thermalrock S60 50 600 1000
158918 Thermalrock S60 75 600 1000
158921 Thermalrock S60 100 600 1000
158923 Thermalrock S80 25 600 1000
158925 Thermalrock S80 50 600 1000
158934 Thermalrock S80 75 600 1000
158937 Thermalrock S80 100 600 1000
200866 Thermalrock S90 50 600 1000
200868 Thermalrock S90 75 600 1000
228064 Thermalrock S90 100 600 1000
158939 Thermalrock S100 25 600 1000
239338 Thermalrock S100 30 600 1000
158942 Thermalrock S100 50 600 1000
158944 Thermalrock S100 75 600 1000
158946 Thermalrock S100 100 600 1000
Reaction to fire
EN13501-1/UL 723 Non-combustible /A1 Fire Classification
20°C λ Value (W/mK) 0.034 - 0.036

Please contact your local representative for more information

Partial immersion Less than 0.23kg/m²

Tools, Guides & Downloads

Thermalrock S Data Sheet_IN
Download
